29A-12
DRIVESHAFTS
Front right-hand driveshaft gaiter, gearbox side: Removal - Refitting
JR5
29A
a Remove the driveshaft yoke sleeve (3) .
a Remove as much grease as possible from inside the
yoke sleeve.
a Remove the lock ring (9) using circlip pliers (10) .
a Extract the spider (5) using a press and a releasing
type extractor.
a Remove the driveshaft gaiter from the driveshaft.
109408
Note:
-Since the driveshaft yoke sleeve does not have
a stop tab, it can be removed without being
forced.
-Do not remove the rollers from their respective
bushings as the rollers and needles are
matched and should never be interchanged.
Note:
Never use thinner to remove grease.
109409
90388
Note:
Mark the position of the spider before extracting
it.
