29A-17
DRIVESHAFTS
Front left-hand driveshaft gaiter, gearbox side: Removal - Refitting
JR5
29A
a Remove the driveshaft yoke sleeve (4) .
a Remove as much grease as possible.
a Remove the lock ring (5) using circlip pliers.
a Remove the spider (6) using a press and a releasing
type extractor.
a Remove:
- the gaiter from the driveshaft,
- the cup equipped with the cup spring.
109408
Note:
- Since the driveshaft yoke sleeve does not have
a stop tab, it can be removed without being
forced,
- do not remove the rollers from their respective
bushings as the rollers and needles are matched
and should never be interchanged.
Note:
Never use thinner to remove grease.
109409
90388
Note:
Mark the position of the spider before extracting
it.
