29A-18
DRIVESHAFTS
Front left-hand driveshaft gaiter, gearbox side: Removal - Refitting
JR5
29A
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: Front left-hand
driveshaft gaiter, gearbox side.
a parts always to be replaced: gearbox side front
driveshaft seal locking ring.
a Always replace:
-the cup,
-the cup spring,
-the big securing clip,
-the small securing clip.
a Use a parts washer to clean the driveshaft, the spi-
der and the driveshaft yoke sleeve.
II - REFITTING OPERATION
a Fit the small tightening clip (2) to the driveshaft.
a Lightly lubricate the driveshaft using the GREASE
supplied with the gaiter to facilitate its fitting.
a Refit the gaiter (3) onto the driveshaft.
a Insert the gaiter lip into the groove of the driveshaft.
a Refit:
- the spider (6) in the position marked during remov-
al,
-a new lock ring using circlip pliers.
128412
128409
109410
