36B-16
POWER ASSISTED STEERING
Power-assisted steering pipes: Removal - Refitting
K4M
36B
a Loosen the clip (3) using tool (Mot. 1448),
a Disconnect the low pressure pipe on the power-as-
sisted steering pump.
a Loosen the clip (5) using tool (Mot. 1448).
a Disconnect the low pressure pipe on the power-as-
sisted steering pump.
a Remove the low pressure pipe between the power-
assisted steering pump and the reservoir.
2 - High pressure pipe between the power-assisted
steering pump and the steering box
a Disconnect the pressure switch connector.
STANDARD HEATING RECIRCULATION
122175
AIR CONDITIONING
116658
