36B-17
POWER ASSISTED STEERING
Power-assisted steering pipes: Removal - Refitting
K4M
36B
a Remove the high pressure pipe bolt (8) from the
multifunction support.
a Remove:
-the high pressure pipe union (7) on the power-as-
sisted steering pump,
-the high pressure pipe on the power-assisted
steering pump.
a Remove:
- the high pressure pipe union (10) on the power-as-
sisted steering pump,
- the high pressure pipe on the power-assisted
steering pump.
STANDARD HEATING RECIRCULATION
122175
AIR CONDITIONING
116658
