36B-21
POWER ASSISTED STEERING
Power-assisted steering pipes: Removal - Refitting
K9K
36B
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove:
-the engine cover,
-the engine undertray.
1 - Low pressure pipe between the power-assisted
steering pump and the reservoir
a Drain the power-assisted steering fluid reservoir us-
ing a syringe.
2 - High pressure pipe between the power-assisted
steering pump and the steering box
a Fit a hose clamp on the power-assisted steering
pump supply pipe.
a Drain the power-assisted steering fluid reservoir us-
ing a syringe.
a Remove the front bumper (see Front bumper: Re-
moval - Refitting) (55A, Exterior protection).
a Remove:
- the front left-hand wheel (see 35A, Wheels and ty-
res, Wheel: Removal - Refitting, page 35A-1) ,
- the front left-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection).
3 - Low pressure pipe between the power-assisted
steering pump and the reservoir
a Fit a hose clamp on the power-assisted steering
pump supply pipe.
Special tooling required
Mot. 1448 Remote operation pliers for
hose clips.
Tightening torquesm
high pressure pipe
union on the steering
box
21 N.m
high pressure pipe bolts
on the gearbox
21 N.m
high pressure pipe
union on the power-
assisted steering pump
assembly
21 N.m
hi gh pressure
pipe bolt on
the power-
assisted
steering pump
assembly21
N.m
high pressure pipe
union on the power-
assisted steering pump
21 N.m
high pressure pipe
clamp bolt on the
power-assisted steering
pump
21 N.m
low pressure pipe union
on the steering box
21 N.m
WARNING
Prepare for the flow of fluid, and protect the sur-
rounding components.
