36B-22
POWER ASSISTED STEERING
Power-assisted steering pipes: Removal - Refitting
K9K
36B
a Drain the power-assisted steering fluid reservoir us-
ing a syringe.
a Remove:
-the front left-hand wheel (see 35A, Wheels and ty-
res, Wheel: Removal - Refitting, page 35A-1) ,
-the front left-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
II - OPERATION FOR REMOVAL OF PART
CONCERNED
1 - Low pressure pipe between the power-assisted
steering pump and the reservoir
a Unclip the low pressure pipe at (1) .
a Loosen the clips (2) using tool (Mot. 1448).
a Disconnect the low pressure pipe on the power-as-
sisted steering pump and on the reservoir.
a Remove the low pressure pipe.
AIR CONDITIONING
STANDARD HEATING RECIRCULATION
24759
24736
