37A-4
MECHANICAL COMPONENT CONTROLS
Master cylinder: Removal - Refitting
LEFT-HAND DRIVE
37A
II - REFITTING OPERATION
a Line up the master cylinder with the brake servo so
that the pushrod goes into the master cylinder hous-
ing.
a Torque tighten the nuts on the brake servo (21
N.m).
a Refit the rigid brake pipe unions.
a Torque tighten the rigid brake pipe unions on the
master cylinder (14 N.m).
a Snap the brake fluid reservoir onto the master cylin-
der correctly at (9) .
a Connect the brake fluid level sensor connector.
III - FINAL OPERATION
a Refit the expansion bottle.
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
a Refit the front engine cover (if fitted to the vehicle).
a Perform the following operations:
-fill up the brake fluid reservoir,
-bleed the brake circuit (see 30A, General informa-
tion, Braking circuit: Bleed, page 30A-4) ,
-bleed the clutch circuit (see 37A, Mechanical
component controls, Clutch circuit: Bleed,
page 37A-37) .
101711
