37A-13
MECHANICAL COMPONENT CONTROLS
Brake servo: Removal - Refitting
LEFT-HAND DRIVE
37A
II - REFITTING OPERATION
a Refit the brake servo.
a Torque tighten the brake servo nuts (21 N.m).
a The shaft connecting the brake servo pushrod and
the brake pedal must be refitted from right to left,
and from top to bottom.
a Refit:
-the insulating foam,
-the special nuts for the insulating foam.
III - FINAL OPERATION
a Refit:
-the non-return valve at the brake servo,
-the master cylinder (see 37A, Mechanical compo-
nent controls, Master cylinder: Removal - Refit-
ting, page 37A-2) .
a Adjust the brake light switch (see 37A, Mechanical
component controls, Brake pedal: Removal - Re-
fitting, page 37A-26) .
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
IMPORTANT
To a void breaking the connection between the
brake servo pushrod and the brake pedal, check
that the safety clevis pin is locked onto the brake
servo pushrod by tilting it from the top down-
wards.
