37A-41
MECHANICAL COMPONENT CONTROLS
Clutch circuit: Bleed
JR5
37A
There are several versions of pipe with and without
a filter:
Pipe without filter.
Filling position for pipe with filter.
Filling position for pipe with filter.
Filling position for pipe with filter.
a Prefill the clutch pipe using the syringe.
a Plug the prefilled pipe on the master cylinder end to
stop any brake fluid from escaping.
141812
141811
141810
141813
