37A-40
MECHANICAL COMPONENT CONTROLS
Clutch circuit: Bleed
JR5
37A
2 - Bleed using a new syringe.
a Keep the clutch pedal in the upper position using a
strap attached to the steering wheel to ensure conti-
nuity of the hydraulic circuit during the bleed opera-
tion.
a Remove the bleed plug from the clutch slave cylin-
der.
a Connect a transparent pipe of sufficient length to the
bleed hole (at least thirty centimetres) in order to
place it at the same height as the reservoir.
a Open the bleed screw.
a Fill the brake fluid master cylinder reservoir until
brake fluid flows out of the bleed screw.
a Connect a new hydraulic circuit bleed syringe
filled with a useful volume of 60 ml of approved
brake fluid to the end of the transparent pipe.
a Slowly inject the entire contents of the syringe into
the hydraulic clutch circuit without injecting any of
the air from the top section of the syringe.
a Close the bleed screw.
a Remove the transparent pipe from the bleed hole.
a Refit the bleed plug.
a Top up the brake fluid level in the master cylinder
reservoir.
a Disengage and engage the clutch quickly around
twenty times.
a Check that the clutch system is operating correctly.
a Repeat the bleed operation if necessary.
a Check the adjustment of the switch. (see 37A, Me-
chanical component controls, Clutch pedal
switch: Removal - Refitting, page 37A-35) (37A,
mechanical control elements).
IV - BLEED PROCEDURE IF PARTS OF THE
HYDRAULIC CIRCUIT ARE REMOVED.
a
Note:
Ta ke care not to disrupt the adjustment of the
clutch start of travel switch.
Note:
The transparent pipe must remain at the same
height as the master cylinder reservoir to prevent
air from entering inside the clutch circuit.
WARNING
The master cylinder pipe must be disconnected
from its take-off point on the brake fluid reservoir,
to avoid any foreign matter penetrating inside the
hydraulic brake circuit.
WARNING
Prepare for the flow of fluid and protect the sur-
rounding components.
Note:
Prefill the hydraulic circuit pipe equipped with a
filter.
Position the filter head facing downwards to
ensure that it fills.
