52A-5
NON-SIDE OPENING ELEMENT MECHANISMS
Bonnet lock: Removal - Refitting
52A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove:
-the front bumper (see 55A, Exterior protection,
Front bumper: Removal - Refitting, page 55A-8)
,
-the air deflector.
II - REMOVAL OPERATION
a Remove nuts (1) .
a Remove the bonnet catch.
a Remove the opening release cable (4) .
REFITTING
a Proceed in the reverse order to removal.
a Torque tighten the bonnet catch nuts (21 N.m).
a Carry out a function test.
Tightening torquesm
bonnet catch nuts 21 N.m
108509
145205
