52A-8
NON-SIDE OPENING ELEMENT MECHANISMS
Tailgate lock: Removal - Refitting
52A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the tailgate trim (see Tailgate trim: Re-
moval - Refitting) (73A, Tailgate trim).
II - REMOVAL OPERATION
a Remove:
-the bolts (2) ,
-the tailgate lock.
a Remove the tailgate lock control linkage.
a Disconnect the tailgate lock connector (3) .
REFITTING
a Proceed in the reverse order to removal.
a Torque tighten the tailgate lock bolts (8 N.m).
a Carry out a function test.
Tightening torquesm
tailgate lock bolts 8 N.m
145580
145581
