62A-7
AIR CONDITIONING
Air conditioning: List and location of components
62A
Fitting G
143992
1 Compressor (see 62A, Air conditioning, Compressor:
Removal - Refitting, page 62A-12)
2 Condenser (see 62A, Air conditioning, Condenser:
Removal - Refitting, page 62A-10)
3 Expansion valve (see 62A, Air conditioning, Expansion valve:
Removal - Refitting, page 62A-16)
4 Pressure sensor (see 62A, Air conditioning, Pressure sensor:
Removal - Refitting, page 62A-23)
5 Expansion valve/intermediate pipe connecting pipe (see 62A, Air conditioning, Refrigerant circuit
pipe: Removal - Refitting, page 62A-21)
6 Intermediate pipe - compressor connecting pipe (see 62A, Air conditioning, Refrigerant circuit
pipe: Removal - Refitting, page 62A-21)
7 Condenser - compressor connecting pipe (see 62A, Air conditioning, Refrigerant circuit
pipe: Removal - Refitting, page 62A-21)
