62A-8
AIR CONDITIONING
Air conditioning: List and location of components
62A
8
Intermediate pipe - expansion valve connecting
pipe (fittings A, B, and C)
(see 62A, Air conditioning, Refrigerant circuit
pipe: Removal - Refitting, page 62A-21)
Condenser - expansion valve connecting pipe (fit-
ting D)
(see 62A, Air conditioning, Refrigerant circuit
pipe: Removal - Refitting, page 62A-21)
Dehydrator reservoir - expansion valve connecting
pipe (fittings F and G)
(see 62A, Air conditioning, Refrigerant circuit
pipe: Removal - Refitting, page 62A-21)
9
Condenser - intermediate pipe connecting pipe (fit-
tings A, B, and C)
(see 62A, Air conditioning, Refrigerant circuit
pipe: Removal - Refitting, page 62A-21)
Condenser - dehydrator reservoir connecting pipe
(fitting F)
(see 62A, Air conditioning, Refrigerant circuit
pipe: Removal - Refitting, page 62A-21)
10 Dehydrator reservoir (fittings F and G) (see Dehydrator reservoir: Removal - Refitting)
