62A-14
AIR CONDITIONING
Compressor: Removal - Refitting
AIR CONDITIONING
62A
a Disconnect the compressor connector (7) .
a Remove:
-the compressor bolts (8) ,
-the compressor.
REFITTING
I - REFITTING PREPARATION OPERATION
a
a Check, and if necessary replace, the refrigerant pipe
seals.
a Clean the surface and the seal of the pipe using EN-
GINE CLEANER (see Vehicle: Parts and con-
sumables for the repair) (04B, Consumables -
Products).
a Use a compressed air gun to blow the surface and
the seal of the connecting pipe.
a Lubricate the surface of the connecting pipe and the
seal with air conditioning oil (see 62A, Air condi-
tioning, Air conditioning: Parts and consum-
ables for the repair, page 62A-9) .
a Remove the blanking plugs.
K9K
145751
WARNING
Do not remove the blanking plugs from each
component until the last moment.
Also, do not remove the components from their
packaging until they are to be fitted to the vehi-
cle.
143880
143882
