62A-20
AIR CONDITIONING
Refrigerant pipe seal: Removal - Refitting
62A
REFITTING
I - REFITTING PREPARATION OPERATION
a Lubricate the surface of the connecting pipe and the
seal with air conditioning oil to make fitting easier
(see 62A, Air conditioning, Air conditioning:
Parts and consumables for the repair, page 62A-
9) .
II - REFITTING OPERATION FOR PART
CONCERNED
a Remove the blanking plugs.
a Refit the seal on the connecting pipe.
III - FINAL OPERATION
a Refit the connecting pipe concerned:
- (see Condenser - evaporator connecting pipe:
Removal - Refitting) ,
- (see Condenser - expansion valve connecting
pipe: Removal - Refitting) ,
- (see Rear condenser - front condenser con-
necting pipe: Removal - Refitting) ,
- (see Evaporator - dehydrator reservoir con-
necting pipe: Removal - Refitting) ,
- (see Compressor - rear condenser connecting
pipe: Removal - Refitting) ,
- (see Condenser - evaporator connecting pipe:
Removal - Refitting) ,
- (see Compressor - dehydrator reservoir con-
necting pipe: Removal - Refitting) ,
- (see Dehydrator reservoir - rear expansion
valve connecting pipe: Removal - Refitting) ,
- (see Main expansion valve - additional expan-
sion valve pipe: Removal - Refitting) ,
- (see Expansion valve - intermediate pipe con-
necting pipe at the expansion valve outlet: Re-
moval - Refitting) ,
- (see Dehydrator reservoir - expansion valve
connecting pipe: Removal - Refitting) ,
- (see Condenser - dehydrator reservoir con-
necting pipe: Removal - Refitting) ,
- (see Expansion valve - compressor connecting
pipe: Removal - Refitting) ,
- (see Expansion valve - rear expansion valve
connecting pipe: Removal - Refitting) ,
- (see Rear expansion valve - compressor con-
necting pipe: Removal - Refitting) ,
- (see Compressor - condenser connecting pipe:
Removal - Refitting) ,
- (see Compressor - intermediate pipe connect-
ing pipe: Removal - Refitting) .
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
a Perform the following operations:
- refill the refrigerant circuit using the refrigerant
charging station (see Refrigerant circuit: Drain-
ing - Filling) ,
- check for leaks (see Refrigerant circuit: Check) .
a Check that the air conditioning system is operating
correctly (see Air conditioning: Check) .
WARNING
To avoid any leaks, check that the seal and the
pipe surface are in good condition. The seal and
the surface must be clean and scratch free.
Note:
A summary table gives the quantities of refriger-
ant in the system according to the engine types
(see 62A, Air conditioning, Air conditioning:
Parts and consumables for the repair, page
62A-9) .
