62C-44
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 5
CONTINUED 1
Is the fault still present? END OF FAULT FINDING
Check fuses F36 and F39 of component 1016.
Are the checks correct?
Replace the faulty fuse.
Using a multimeter in the voltmeter position, check for +12 V on connection SP3 and BP1 of component 233 and
earth MAM of component 233.
Are the checks correct?
Check for earth on connection MAM of
component 233.
Repair the wiring. If there is a repair
method (see Technical Note 6015A,
Repairing electrical wiring, Wiring:
Precautions for repair), repair or replace
the wiring.
Is the result of the check correct?
A
NO
YES
NO
YES
B
YES
NO
NO
H
YES
To Next Page
