62C-43
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 5 No passenger compartment ventilation
NOTES Check that fuses F39 and F36 are in good condition.
Check that the air circuit (cabin filter, scuttle panel grille, air ducts, etc.) is not blocked.
Is the air circuit in good condition?
If necessary, repair, clean or replace the cabin filter
(see MR 451 Mechanical, 61A, Heating, Cabin filter:
Removal - Refitting).
Check the condition of the passenger compartment blower blades
Are the passenger compartment blower blades in good condition?
Check that the air recirculation flap does not
remain closed when in the recirculation position.
Repair if necessary.
If necessary, repair, clean or replace the
passenger compartment blower blades
(see MR 451 Mechanical, 61A, Heating,
Fan assembly: Removal - Refitting).
Ensure that all the air vents are open.
Repair if necessary.
YES
NO
YES NO
A
To Next Page
