62C-46
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 5
CONTINUED 3
Carry out a continuity test on connection 38AH between components 319 and 164.
Is the continuity correct?
Carry out a continuity test on connection 38AJ
between components 319 and 164.
Fault on connection 38AH between components 319 and
164. Repair the wiring.
If there is a repair procedure (see Technical Note 6015A,
Repairing electrical wiring, Wiring: Precautions for
repair), repair the wiring, otherwise replace it.
Is the continuity correct?
Carry out a continuity test on connection 38AK
between components 319 and 164.
Fault on connection 38AJ between components 319 and
164. Repair the wiring. If there is a repair procedure (see
Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring,
otherwise replace it.
Is the continuity correct?
C
YES NO
YES NO
YES
D
NO
E
To Next Page
