AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 5
CONTINUED 4
Carry out a continuity test on connection 38AK
between components 319 and 164.
Fault on connection 38AK between components 319 and
164. Repair the wiring. If there is a repair procedure
(see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring,
otherwise replace it.
Is the continuity correct?
Fault on connection 38AL between components 319 and
164. Repair the wiring. If there is a repair procedure (see
Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring,
otherwise replace it.
Carry out a continuity test on connection 38DB
between components 319 and 164.
Is the continuity correct?
D E
YES
NO
YES
F
NO
G
