AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 5
CONTINUED 5
Fault on connection 38DB between components 319 and 164. Repair
the wiring. If there is a repair procedure (see Technical Note 6015A,
Repairing electrical wiring, Wiring: Precautions for repair), repair
the wiring, otherwise replace it.
Check for earth on
connection MAN of
component 164
(fan assembly).
Is the result of the check
correct?
Repair the wiring. If there is a repair procedure (see Technical Note
6015A, Repairing electrical wiring, Wiring: Precautions for repair),
repair the wiring, otherwise replace it.
Replace fan assembly 1
(see MR 451 Mechanical,
61A, Heating, Passenger
compartment fan assembly
control unit: Removal -
Refitting).
F
YES
G
NO
NO
YES
