Renault Duster 2007 - Page 824

62C-49
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 5
CONTINUED 6
Test the continuity on connection SP3 between component 233 and fuse F39 of component 1016.
Is the continuity correct?
Repair the wiring. If there is a repair method
(see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for
repair), repair or replace the wiring.
Test the continuity on connection BP1 between
component 233 and fuse F36 of component 1016.
Is the continuity correct?
Repair the wiring. If there is a repair method
(see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for
repair), repair or replace the wiring.
H
YES NO
NO
YES
B
