62C-61
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 9
CONTINUED 1
If there is a repair
procedure (see
Technical Note 6015A,
Repairing electrical
wiring, Wiring:
Precautions for
repair), repair the
wiring, otherwise
replace it.
With the vehicle ignition
off, check that the
compressor clutch relay
is not "jammed", by
checking the continuity
between connection
38R and connection
BP7 of component 784.
Replace the air conditioning compressor (see MR 451,
Mechanical, 62A, Air conditioning, Compressor:
Removal - Refitting).
Is the continuity
present?
Replace the air conditioning compressor
clutch relay
Apply the fault finding
procedure of command
(depending on version)
AC180 Air conditioning
compressor relay control,
AC003 or AC070 Air
conditioning compressor
(see 13B, Diesel injection
or 17B, Petrol injection).
Is the fault still present?
B
NO
C
YES
D
YES
YES
NO
A
To Next Page
