62C-62
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 9
CONTINUED 2
With the engine warm and the passenger
compartment ventilation operating, vary the position
of the mixing flap from the maximum cold position to
the maximum hot position and check subjectively
that there is a difference in temperature.
Is a difference in temperature noted? Check the condition and routing of the mixing
flap control cable. Eliminate any constraints
on the cable: kinks, restricted by plastic clips,
etc. Replace it if necessary. Unclip the cable
from the side of the unit and check the
stiffness of movement of each component:
control button and flap control on the air
distribution unit. Check that there is no
mechanical fault on the mixing flap (flap
jammed inside the unit, etc.).
Carry out any necessary repairs.
A
NO
YES
E
