62C-67
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 10
CONTINUED 3
Press the de-icing button on the control
panel and check for earth on connection
15M of component 235.
Continuity fault on connection 15M. Use an ohmmeter to
perform a continuity test on connection 15M between
components 235 and 645. If there is a repair method
(see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair or replace the
wiring.
Is the result of the check correct?
Connect a test light between connection
AP7 of component 235 and a chassis
earth.
Continuity fault on connection AP7. Use an ohmmeter to
test the continuity on connection AP7 between component
235 and fuse F01 of component 1016. If there is a repair
method (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair or replace
the wiring.
Does the test bulb illuminate?
Connect a test light between connection
BP15 of component 235 and a chassis
earth.
Does the test bulb illuminate?
Continuity fault on connection BP15. Use an ohmmeter to
test the continuity on connection BP15 between
component 235 and fuse F32 of component 1016. If there
is a repair procedure (see Technical Note 6015A,
Electrical wiring repair, Wiring: Precautions for repair),
repair the wiring, otherwise
replace the wiring.
B
NO
YES
NO
YES
NO
YES
C
To Next Page
