AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 10
CONTINUED 4
Connect a test light between connection
15LP of component 200 and a chassis
earth.
Does the test bulb illuminate?
Check the continuity of connection 15LP between
components 235 and 200.
Is the connection OK?
Replace the heated rear screen
relay (component code 235).
If there is a repair method
(see Technical Note 6015A,
Repairing electrical wiring,
Wiring: Precautions for repair),
repair or replace the wiring.
Check for earth on connection MG of
component 200.
If there is a repair method (see Technical Note
6015A, Repairing electrical wiring, Wiring:
Precautions for repair), repair or replace the wiring.
Is the result of the check correct?
Replace the rear screen.
