62C-72
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 13 No lighting on the control panel in night mode
NOTES
Check fuse F19 or F18 (depending on model: F19 for left-hand drive and F18 for right-
hand drive) of component 1016.
Check fuse F19 (left-hand drive)
or F18 (right-hand drive) of
component 1016.
Is the test correct?
Replace the faulty fuse.
Using a test light, check for +12 V between connection LPD or LPG (depending on model) and connection NC of
component 319.
Does the test bulb illuminate?
Check the condition of the air conditioning
control panel bulbs.
Perform a continuity test on connection LPD
(or LPG) between component 319 and F19 (left-
hand drive) or F18 (right-hand drive) of
component 1016.
NO
YES
YES
A
NO
B
C
