62C-73
AFTER REPAIR Carry out a full check with the diagnostic tool.
V1
MR-453-X79-62C000$080.mif
CLIMATE CONTROL
Fault finding – Fault finding chart
62C
ALP 13
CONTINUED
Are the bulbs sound? Is the test correct?
Replace the air
conditioning control
panel.
Replace the air
conditioning control
panel bulb(s).
Check for earth
on connection
NC of
component
319.
Fault on connection
LPD or LPG between F19
(left-hand drive) or F18
(right-hand drive) of
components 1016 and
319. Repair the wiring.
If there is a repair method
(see Technical Note
6015A, Repairing
electrical wiring, Wiring:
Precautions for repair),
repair or replace the
wiring.
Is the test correct?
Fault on connection NC. Repair the wiring. If there is a
repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair
the wiring, otherwise replace it.
B C
YES NO YES NO
YES
A
NO
To Next Page
