75A-2
FRONT SEAT FRAMES AND MECHANISMS
Front seat assembly: Exploded view
DRIVER HEIGHT ADJUSTER
75A
14 Bolt of front seat base exterior cas-
ing
16 Front seat base exterior casing
17 Front seat lumbar adjustment
mechanism
Mark Description Information
FRONT SIDE AIRBAG or FRONT SIDE + CUR-
TAIN AIRBAG
Mark Description Information
7 Front seat chest-level side airbag
dummy module
10 Front seat chest-level side airbag (see Front (chest-level) side air-
bag: Removal - Refitting)
18 Bolt of front seat chest-level side
airbag dummy module
FRONT SEAT WITH HEATING
Mark Description Information
13 Front seat heated pad switch
15 Front seat base exterior casing
