75A-3
FRONT SEAT FRAMES AND MECHANISMS
Front seat assembly: Exploded view
DRIVER HEIGHT ADJUSTER
75A
(see )
146025
Mark Description Information
1 Seat trim clip (Car.1521)
2 Front seatback cover (see )
3 Front seat base cover (see )
4 Front seat headrest (see )
5 Front seat back foam
6 Front seat base foam
FRONT SIDE AIRBAG, and FRONT SEAT WITH
HEATING, and WITH SEAT BELT NOT SECURED
WARNING
Mark Description Information
9 Front seat electrical wiring
