82A-3
ENGINE IMMOBILISER
Ignition switch: Removal - Refitting
82A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Disconnect the battery (see 80A, Battery, Battery:
Removal - Refitting, page 80A-2) .
a Remove the transponder ring (see 82A, Engine im-
mobiliser, Transponder ring: Removal - Refit-
ting, page 82A-5) .
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Unclip the connector from its support at (1) and (2)
from underneath the dashboard.
a Unclip the connector using a flat-blade screwdriver.
a Remove the bolt (3) .
a Move the ignition key to position (5) .
a Tilt the retaining lugs (4) .
a Remove switch.
REFITTING
I - REFITTING PREPARATION OPERATION
a Always replace the switch bolt.
107851
107849
127941
