83A-1
INSTRUMENT PANEL
Instrument panel: Removal - Refitting
83A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a When replacing the instrument panel, read the mile-
age indicated on the instrument panel and note it in
the warranty booklet (see insert in the introduction)
a Switch off the ignition.
a Remove the two lower bolts (1) .
a Unclip:
-the lower half-shell in the direction of the arrow (2) ,
-the upper half-shell.
a Unclip the central trim assembly (3) , starting at the
bottom.
a Unclip the trims (4) .
When replacing the instrument panel, the following
must be noted on the warranty booklet:
- that the instrument panel has been replaced,
- the mileage indicated by the instrument panel
removed.
107813
125471
125472
