84A-5
CONTROL - SIGNALS
Screen wiper switch: Removal - Refitting
84A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Switch off the ignition.
a Remove the transponder ring (see 82A, Engine im-
mobiliser, Transponder ring: Removal - Refit-
ting, page 82A-5) .
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Remove the two bolts (1) from the wiping stalk.
a Remove the wiping stalk from its support.
a Disconnect the connector.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Connect the connector.
a Refit:
-the wiping stalk onto its support,
-the bolts to the wiping stalk.
II - FINAL OPERATION.
a Refit the transponder ring (see 82A, Engine immo-
biliser, Transponder ring: Removal - Refitting,
page 82A-5) .
108742
