84A-6
CONTROL - SIGNALS
Signals and lighting switch: Removal - Refitting
84A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Switch off the ignition.
a Remove:
-both bolts (1) ,
-the lower half-shell at (2) .
a Remove the upper half cowling.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Remove the two bolts (3) from the lighting stalk.
a Remove the lighting stalk and its mounting.
a Disconnect the connector.
Note:
The steering wheel does not need to be
removed.
107813
107814
108741
