84A-13
CONTROL - SIGNALS
Heated rear screen switch: Removal - Refitting
84A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the radio (see 86A, Radio, Radio: Remov-
al - Refitting, page 86A-3) .
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the connector (1) from the rear screen
de-icing switch.
a Unclip the heated rear screen switch by moving the
clips.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Clip on the heated rear screen switch.
a Connect the connector to the heated rear screen
switch.
II - FINAL OPERATION.
a Clip on the central trim assembly, starting at the top.
a Refit the radio (see 86A, Radio, Radio: Removal -
Refitting, page 86A-3) .
125727
