84A-14
CONTROL - SIGNALS
Heated seat pad switch: Removal - Refitting
FRONT SEAT WITH HEATING
84A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove:
-the bolt (1) from the exterior runner cover,
-the exterior runner cover.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Unclip the heated seat cover switch (2) .
a Disconnect the heated seat cover switch connector.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Connect the heated seat cover switch connector.
a Clip on the heated seat cover switch.
II - FINAL OPERATION.
a Refit:
-the exterior runner cover,
-the exterior runner cover bolt.
24693
