85A-1
WIPING - WASHING
Wiping and washing: List and location of components
85A
I - LIST OF COMPONENTS
II - LOCATION OF COMPONENTS
1 - UCH
UCH (1)
2 - PASSENGER COMPARTMENT FUSE BOX
Passenger compartment fuse box (2)
3 - WINDSCREEN WIPER SWITCH
Windscreen wiper switch (3)
No. Description
(1) UCH
(2) Passenger compartment fuse box
(3) Windscreen wiper switch
(4) Windscreen wiper motor
(5) Rear screen wiper motor
(6) Washer pump
(7) Windscreen washer bottle
107848
107820
107815
