85A-3
WIPING - WASHING
Windscreen wiper blade: Removal - Refitting
85A
REMOVAL
OPERATION FOR REMOVAL OF PART
CONCERNED
a Lift the wiper arm.
a Swivel the blade so it is perpendicular to the wiper
arm.
a Squeeze the clips (1) and move downwards at the
same time (2) .
a Remove the blade.
REFITTING
REFITTING OPERATION FOR PART CONCERNED
a Clip the blade onto the wiper arm.
a Lower the wiper arm.
118618
