85A-15
WIPING - WASHING
Front screen washer jet: Removal - Refitting
85A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Disconnect the jet supply pipe.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Unclip the windscreen washer jet by prising the clips
(1) using a flat screwdriver.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Clip the washer jet.
II - FINAL OPERATION
a Connect the jet supply pipe.
a Check that the assembly works correctly.
a Adjust the position of the rear windscreen washer jet
if necessary using a needle.
108636
118887
Note:
Ta k e c are not to damage the paintwork on the
bonnet.
