85A-16
WIPING - WASHING
Rear screen washer jet: Removal - Refitting
REAR SCREEN WIPER
85A
REMOVAL
I - REMOVAL PREPARATION OPERATION
II - REMOVAL OPERATION
a Unclip the rear screen washer jet (2) using tool (Car.
1363).
a Disconnect the rear screen washer jet supply pipe.
REFITTING
I - REFITTING OPERATION
a Connect the rear screen washer jet supply pipe.
a Clip the rear screen washer jet.
II - FINAL OPERATION
Special tooling required
Car. 1363 Set of trim removal levers.
126625
