88A-12
WIRING HARNESS
Engine wiring: Removal - Refitting
K4M
88A
REFITTING
I - REFITTING PREPARATION OPERATION
If replacing the engine wiring
a Refit the fuses.
a If replacing with a complete wiring harness, lock the
unused connectors (see Connectors: Sealing and
locking) (Technical Note 6015A, 88A, Wiring).
II - REFITTING OPERATION
a Proceed in the reverse order to removal.
a Torque tighten:
-the manual gearbox earth cable bolt (24 N.m),
-the earth cable nuts (8 N.m).
a Connect the battery (see 80A, Battery, Battery: Re-
moval - Refitting, page 80A-2) (80A, Battery).
III - TEST OPERATION
a Switch on the ignition.
a Connect the Diagnostic tool.
a Check that there are no faults.
Note:
Refit the earth terminal, aligning the indelible
marks on the gearbox casing.
When reassembling, improper positioning of the
earth terminal on the gearbox casing could result
in damage to the earth terminal or earth wiring.
