Data TLB Protection Violation Exception:
• Source: The access does not accord with the UTLB protection information (PR bits) shown
below.
PR Privileged Mode User Mode
00 Only read access possible Access not possible
01 Read/write access possible Access not possible
10 Only read access possible Only read access possible
11 Read/write access possible Read/write access possible
• Transition address: VBR + H'00000100
• Transition operations:
The virtual address (32 bits) at which this exception occurred is set in TEA, and the
corresponding virtual page number (22 bits) is set in PTEH [31:10]. ASID in PTEH indicates
the ASID when this exception occurred.
The PC and SR contents for the instruction at which this exception occurred are saved in SPC
and SSR. The R15 contents at this time are saved in SGR.
Exception code H'0A0 (for a read access) or H'0C0 (for a write access) is set in EXPEVT. The
BL, MD, and RB bits are set to 1 in SR, and a branch is made to PC = VBR + H'0100.
Data_TLB_protection_violation_exception()
{
TEA = EXCEPTION_ADDRESS;
PTEH.VPN = PAGE_NUMBER;
SPC = PC;
SSR = SR;
SGR = R15;
EXPEVT = read_access ? H'0000 00A0 : H'0000 00C0;
SR.MD = 1;
SR.RB = 1;
SR.BL = 1;
PC = VBR + H'0000 0100;
}
