Rev. 1.50, 10/04, page 38 of 448
Instruction Operation Instruction Code Privileged T Bit New
LDC Rm,SPC Rm → SPC
0100mmmm01001110
Privileged — —
LDC Rm,DBR Rm → DBR
0100mmmm11111010
Privileged — —
LDC Rm,Rn_BANK Rm → Rn_BANK (n = 0 to 7)
0100mmmm1nnn1110
Privileged — —
LDC.L @Rm+,SR (Rm) → SR, Rm + 4 → Rm
0100mmmm00000111
Privileged LSB —
LDC.L @Rm+,GBR (Rm) → GBR, Rm + 4 → Rm 0100mmmm00010111 — — —
LDC.L @Rm+,VBR (Rm) → VBR, Rm + 4 → Rm 0100mmmm00100111 Privileged — —
LDC.L @Rm+,SGR (Rm) → SGR, Rm + 4 → Rm 0100mmmm00110110 Privileged — —
LDC.L @Rm+,SSR (Rm) → SSR, Rm + 4 → Rm 0100mmmm00110111 Privileged — —
LDC.L @Rm+,SPC (Rm) → SPC, Rm + 4 → Rm 0100mmmm01000111 Privileged — —
LDC.L @Rm+,DBR (Rm) → DBR, Rm + 4 → Rm 0100mmmm11110110 Privileged — —
LDC.L @Rm+,Rn_BANK (Rm) → Rn_BANK,
Rm + 4 → Rm
0100mmmm1nnn0111 Privileged — —
LDS Rm,MACH Rm → MACH 0100mmmm00001010 — — —
LDS Rm,MACL Rm → MACL 0100mmmm00011010 — — —
LDS Rm,PR Rm → PR 0100mmmm00101010 — — —
LDS.L @Rm+,MACH (Rm) → MACH, Rm + 4 → Rm 0100mmmm00000110 — — —
LDS.L @Rm+,MACL (Rm) → MACL, Rm + 4 → Rm 0100mmmm00010110 — — —
LDS.L @Rm+,PR (Rm) → PR, Rm + 4 → Rm 0100mmmm00100110 — — —
LDTLB PTEH/PTEL → TLB 0000000000111000 Privileged — —
MOVCA.L R0,@Rn R0 → (Rn) (without fetching
cache block)
0000nnnn11000011 — — —
NOP No operation 0000000000001001 — — —
OCBI @Rn Invalidates operand cache
block
0000nnnn10010011 — — —
OCBP @Rn Writes back and invalidates
operand cache block
0000nnnn10100011 — — —
OCBWB @Rn Writes back operand cache
block
0000nnnn10110011 — — —
PREF @Rn (Rn) → operand cache 0000nnnn10000011 — — —
PREFI @Rn Reads 32-byte instruction
block into instruction cache
0000nnnn11010011   New
RTE Delayed branch, SSR/SPC →
SR/PC
0000000000101011 Privileged — —
SETS 1 → S 0000000001011000 — — —
SETT 1 → T 0000000000011000 — 1 —
SLEEP Sleep or standby 0000000000011011 Privileged — —
STC SR,Rn SR → Rn 0000nnnn00000010 Privileged — —
STC GBR,Rn GBR → Rn 0000nnnn00010010 — — —
