Renesas SuperH SH-4A User Manual

Rev. 1.50, 10/04, page 61 of 448
Functional
Category
No. Instruction
Instruction
Group
Issue Rate
Execution
Cycles
Execution
Pattern
126 CLRT EX 1 1 2-1
127 ICBI @Rn CO 8+5+3 13 3-6
128 SETS EX 1 1 2-1
129 SETT EX 1 1 2-1
130 PREFI CO 5+5+3 10 3-7
131 SYNCO @Rn CO Undefined Undefined 3-4
132 TRAPA #imm CO 8+5+1 13 1-5
133 RTE CO 4+1 4 1-4
134 SLEEP CO Undefined Undefined 1-6
135 LDTLB CO 1 1 3-5
136 LDC Rm,DBR CO 4 4 4-2
137 LDC Rm,SGR CO 4 4 4-2
138 LDC Rm,GBR LS 1 1 4-3
139 LDC Rm,Rp_BANK LS 1 1 4-1
140 LDC Rm,SR CO 4+3 4 4-4
141 LDC Rm,SSR LS 1 1 4-1
142 LDC Rm,SPC LS 1 1 4-1
143 LDC Rm,VBR LS 1 1 4-1
144 LDC.L @Rm+,DBR CO 4 4 4-6
145 LDC.L @Rm+,SGR CO 4 4 4-6
146 LDC.L @Rm+,GBR LS 1 1 4-7
147 LDC.L @Rm+,Rp_BANK LS 1 1 4-5
148 LDC.L @Rm+,SR CO 6+3 4 4-8
149 LDC.L @Rm+,SSR LS 1 1 4-5
150 LDC.L @Rm+,SPC LS 1 1 4-5
151 LDC.L @Rm+,VBR LS 1 1 4-5
152 LDS Rm,MACH LS 1 1 5-1
153 LDS Rm,MACL LS 1 1 5-1
154 LDS Rm,PR LS 1 1 4-13
155 LDS.L @Rm+,MACH LS 1 1 5-2
156 LDS.L @Rm+,MACL LS 1 1 5-2
System
control
instructions
157 LDS.L @Rm+,PR LS 1 1 4-14
