Renesas SuperH SH-4A User Manual

Rev. 1.50, 10/04, page 62 of 448
Functional
Category
No. Instruction
Instruction
Group
Issue Rate
Execution
Cycles
Execution
Pattern
158 STC DBR,Rn LS 1 1 4-9
159 STC SGR,Rn LS 1 1 4-9
160 STC GBR,Rn LS 1 1 4-9
161 STC Rp_BANK,Rn LS 1 1 4-9
162 STC SR,Rn CO 1 1 4-10
163 STC SSR,Rn LS 1 1 4-9
164 STC SPC,Rn LS 1 1 4-9
165 STC VBR,Rn LS 1 1 4-9
166 STC.L DBR,@-Rn LS 1 1 4-11
167 STC.L SGR,@-Rn LS 1 1 4-11
168 STC.L GBR,@-Rn LS 1 1 4-11
169 STC.L Rp_BANK,@-Rn LS 1 1 4-11
170 STC.L SR,@-Rn CO 1 1 4-12
171 STC.L SSR,@-Rn LS 1 1 4-11
172 STC.L SPC,@-Rn LS 1 1 4-11
173 STC.L VBR,@-Rn LS 1 1 4-11
174 STS MACH,Rn LS 1 1 5-3
175 STS MACL,Rn LS 1 1 5-3
176 STS PR,Rn LS 1 1 4-15
177 STS.L MACH,@-Rn LS 1 1 5-4
178 STS.L MACL,@-Rn LS 1 1 5-4
System
control
instructions
179 STS.L PR,@-Rn LS 1 1 4-16
180 FLDI0 FRn LS 1 1 6-13
181 FLDI1 FRn LS 1 1 6-13
182 FMOV FRm,FRn LS 1 1 6-9
183 FMOV.S @Rm,FRn LS 1 1 6-9
184 FMOV.S @Rm+,FRn LS 1 1 6-9
185 FMOV.S @(R0,Rm),FRn LS 1 1 6-9
186 FMOV.S FRm,@Rn LS 1 1 6-9
187 FMOV.S FRm,@-Rn LS 1 1 6-9
Single-
precision
floating-point
instructions
188 FMOV.S FRm,@(R0,Rn) LS 1 1 6-9
