Renesas SuperH SH-4A User Manual

Rev. 1.50, 10/04, page 63 of 448
Functional
Category
No. Instruction
Instruction
Group
Issue Rate
Execution
Cycles
Execution
Pattern
189 FLDS FRm,FPUL LS 1 1 6-10
190 FSTS FPUL,FRn LS 1 1 6-11
191 FABS FRn LS 1 1 6-12
192 FADD FRm,FRn FE 1 1 6-14
193 FCMP/EQ FRm,FRn FE 1 1 6-14
194 FCMP/GT FRm,FRn FE 1 1 6-14
195 FDIV FRm,FRn FE 1 14 6-15
196 FLOAT FPUL,FRn FE 1 1 6-14
197 FMAC FR0,FRm,FRn FE 1 1 6-14
198 FMUL FRm,FRn FE 1 1 6-14
199 FNEG FRn LS 1 1 6-12
200 FSQRT FRn FE 1 30 6-15
201 FSUB FRm,FRn FE 1 1 6-14
202 FTRC FRm,FPUL FE 1 1 6-14
203 FMOV DRm,DRn LS 1 1 6-9
204 FMOV @Rm,DRn LS 1 1 6-9
205 FMOV @Rm+,DRn LS 1 1 6-9
206 FMOV @(R0,Rm),DRn LS 1 1 6-9
207 FMOV DRm,@Rn LS 1 1 6-9
208 FMOV DRm,@-Rn LS 1 1 6-9
Single-
precision
floating-point
instructions
209 FMOV DRm,@(R0,Rn) LS 1 1 6-9
210 FABS DRn LS 1 1 6-12
211 FADD DRm,DRn FE 1 1 6-16
212 FCMP/EQ DRm,DRn FE 1 1 6-16
213 FCMP/GT DRm,DRn FE 1 1 6-16
214 FCNVDS DRm,FPUL FE 1 1 6-16
215 FCNVSD FPUL,DRn FE 1 1 6-16
216 FDIV DRm,DRn FE 1 14 6-18
217 FLOAT FPUL,DRn FE 1 1 6-16
218 FMUL DRm,DRn FE 1 3 6-17
Double-
precision
floating-point
instructions
219 FNEG DRn LS 1 1 6-12
