Table 6-6 continued. READ mode parameters for RFL 9300 Three-Terminal Charge Comparison Systems
83 R2 FD PH Remote 2 fault detector phase current.
84 R2 FD GD Remote 2 fault detector ground current.
85 R2 BCKUP Remote 2 backup functions.
86 R2 PH OC Remote 2 phase overcurrent backup.
87 R2 GD OC Remote 2 ground overcurrent backup.
88 R2 P TOC Remote 2 phase inverse time-overcurrent backup.
89 R2 PPKUP Remote 2 phase inverse time-overcurrent pickup value.
90 R2 PCURV Remote 2 phase inverse time-overcurrent curve select value.
91 R2 PDIAL Remote 2 phase inverse time-overcurrent dial setting value.
92 R2 G TOC Remote 2 ground inverse time-overcurrent backup.
93 R2 GPKUP Remote 2 ground inverse time-overcurrent pickup value.
94 R2 GCURV Remote 2 ground inverse time-overcurrent curve select value.
95 R2 GDIAL Remote 2 ground inverse time-overcurrent dial setting value.
96 R2 OH/UG Remote 2 overhead or underground.
97 R2 OP/CN Remote 2 open conductor action. (7)
98 R2 STUB Remote 2 stub bus action.
100 R2 GD TP Remote 2 guard before trip
101 R2 PNGPG Remote 2 ping-pong (round-trip delay).
103 SWID CC1 Software version number for local communications controller in two-terminal systems.
104 SWID CC2 Software version number for second local communications controller in three-terminal systems.
105 SWID SV Software version number for local supervisor module.
106 SWID PCA Software version number for local Phase Controller "A" module.
107 SWID PCB Software version number for local Phase Controller "B" module.
108 SWID PCC Software version number for local Phase Controller "C" module.
109 SWID PCG Software version number for local Phase Controller "G" module.
110 SWID DC Software version number for local display module.
111 EXIT Exit to STANDBY mode. Same as parameter #0. (1)
140 SGL POLE Single-Pole trip – active/inactive
141 SEL POLE Enable/Disable Selective pole relaying – Programmable; see table 6-9 for more information (8)
145 TRIP RLS Trip release codes – Programmable; see table 6-9 for more information
160 RS1 POLE Remote 1 single-pole trip – active/inactive
161 R1 SEL P Remote 1 Selective pole relaying
165 TRP RLS 1 Remote 1 Trip release codes
180 RS2 POLE Remote 2 single-pole trip – active/inactive
181 R2 SEL P Remote 2 Selective pole relaying
185 TRP RLS 2 Remote 2 Trip release codes
>> Refer to page 6-24 for notes <<
