The Remote Parameters screen shows the code number for each item, a brief description of its meaning, and
its setting. Full descriptions for each item are as follows:
053 - R1 Phase Bias Remote 1 Phase Bias setting in amperes. Can be set from 1.0 to 8.0 amperes
in 0.5 ampere steps.
054 - R1 Ground Bias Remote 1 Ground Bias setting in amperes. Can be set from 1.0 to 2.25 am-
peres in 0.25 ampere steps.
055 - R1 Bias Control Remote 1 Bias Control. Can be enabled or disabled.
056 - R1 Ground Delay Remote 1 Ground Delay function. Can be enabled or disabled.
057 - R1 Bias/Gnd Dly Remote 1 Bias Control and Ground Delay time.
058 - R1 FD Phase Remote 1 Phase Overcurrent Fault Detector. Can be set to 6.0 or 8.0 amperes.
059 - R1 FD Ground Remote 1 Ground Overcurrent Fault Detector current. Can be set to 0.5 or 1.0
amperes.
060 - R1 Backup Remote 1 System Backup functions. Can be enabled or disabled.
061 - R1 Ph O/C Bkup Remote 1 Phase Overcurrent Backup function. Can be set from 6.0 to 31.875
amperes in 0.125 ampere steps.
062 - R1 Gnd O/C Bkup Remote 1 Ground Overcurrent Backup function. Can be set from 6.0 to 31.875
amperes in 0.125 ampere steps.
063 - R1 Phase TOC Remote 1 Phase Inverse Time-overcurrent function. Can be enabled or dis-
abled. See note below.
064 - R1 Ph TOC Pickup Remote 1 Phase Inverse Time-overcurrent Pickup value. Can be set from 0.5
to 31.875 amperes in 0.125 ampere steps.
065 - R1 Ph TOC Curve Remote 1 Phase Inverse Time-overcurrent Curve select. Refer to note 6 on
page 6-28 for settings.
066 - R1 Ph TOC Dial Remote 1 Phase Inverse Time-overcurrent Dial setting. Refer to note 6 on page
6-28 for settings.
067 - R1 Ground TOC Remote 1 Ground Inverse Time-overcurrent function. Can be enabled or dis-
abled. See note below.
068 - R1 Gd TOC Pickup Remote 1 Ground Inverse Time-overcurrent Pickup value. Can be set from 0.5
to 31.0 amperes in 0.125 ampere steps.
069 - R1 Gd TOC Curve Remote 1 Ground Inverse Time-overcurrent Curve select. Refer to note 7 on
page 6-28 for settings.
070 - R1 Gd TOC Dial Remote 1 Ground Inverse Time-overcurrent Dial setting. Refer to note 7 on
page 6-28 for settings.
NOTE
If parameter No. 063 is disabled, then parameter numbers 065 and 066 will display N/A (not applicable).
If parameter No. 067 is disabled, then parameter numbers 069 and 070 will display N/A (not applicable).
RFL 9300 RFL Electronics Inc.
January 30, 2002 6-48 (973) 334-3100
