8.2.3 SINGLE-RELAY TEST PROCEDURES
There are five single-relay tests:
Description Of Test
Paragraph
Familiarization 8.2.3.1
Alarm Conditions 8.2.3.2
Direct Transfer Trip 8.2.3.3
Internal Faults 8.2.3.4
Backup Tripping, High-Set Overcurrent 8.2.3.5
Before performing any single-relay tests, carefully read the procedures in Section 6 of this manual. In particular,
review the information on the READ mode and PROGRAM mode. These modes will be used many times during
the procedures described in this section. Also, make sure that the modules are using the latest software ver-
sions as described in paragraph 6.1 of this manual. Set up the system relay parameters in accordance with
paragraph 7.3.
Perform all steps in each test procedure in the order shown, unless otherwise directed. Expected results and/or
comments are indented and appear in boldface type.
